Model：HZS50
Maximum productivity(m³/h)： 50
Discharging height(m)： 4.2
Working cycle time(s)： 72
Outline dimension(mm)： 15689×12500×18704
Total power (kw)： 88
Total weight： 28T
with high performance cost ratio for construction projects
TRUSEEN can easily cover its customers requests with its stationary concrete batching plants in different capacities and specifications.
TRUSEEN has a wide range of Stationary Concrete Batching Plants which have production capacity from 25 m³/h to 180 m³/h with one mixer. In addition， the capacity of Stationary Concrete Batching Plants can be from 240 m³/h to 360 m³/h with double mixers on the same chassis.
HZS50 concrete batching plant is one of the best-selling plant. It mainly used in projects such as roads, bridges and other large construction projects.
Theory Capacity: 50m³/h
It is composed of mixing，batching and electrical control system etc.
Adopting twin shaft & double motors make it gets higher mixing power.
Hopper feeder ensures small layout room under limited cost making whole plant easily working effective.
Electrical control system main components are all imported reliable performance easy operation the print function.
Aluminum alloy butterfly valve & accurate weighing device work automatically with PLD1600 feeder/PLC+PC system.The quantity of cement silo and screw conveyor can be choosed by users.
Modular design is easy to install and remove.
All above features spark HZS50 automatically. It also has best cost performance.
Model HZS25 HZS35 HZS50 HZS75 Global parameter Maximum productivity (m³/h) 25 35 50 75 Discharging height (m) 1.5–3.8 1.6–3.8 4.2 4.2 Working cycle time(s) 72 72 72 72 Outline dimension(mm) 11693×13060×
17245
12922×13000×
17245
15689×12500×
18704
17608×12500×
18704
Total power (kw) 50 75 88 110 Mixer Model JS500 JS750 JS1000 JS1500 Batcher Model PLD800 PLD1200 PLD1600 PLD2400 Pneumatic system Air compressor 1.0–7 1.0–7 1.5–7 1.8–7 Discharge pressure(MPa) 0.8 0.8 0.8 0.8 Displacement (m³/min) 1.67 1.67 1.67 1.67 Motor power 5.5 5.5 7.5 11 Measurement system Aggregate weighing accuracy ±2% ±2% ±2% ±2% Cement weighing accuracy ±1% ±1% ±1% ±1% Water weighing accuracy ±1% ±1% ±1% ±1% Additive weighing accuracy ±1% ±1% ±1% ±1%
