1.Excellent manufacturing team with experience of over 30 years.

2.All can be customized to meet your needs&boost productivity.

3.Passed CE&ISO9001:2008 quality attestation.

4.Long-term cooperated transport company ensure the timely and safe delivery.

5.One-stop service save your precious time.

Concrete Mixer Pump

  • The concrete mixer pump is compact structure, can pump both big & fine size concrete , slurry and so on. It is used in the project of small capacity and easy movable. These mixer pumps also have diesel type, which can use in the place without electricity.



    ● with experienced technology, the pump have reliable quality.

    ● with double layer design, the electric control panel have good sealed, water@dust proof.

    ● famous brand for PLC, so it is easy to control.

    ● use wear resistant alloy material , the mixer can use long time.

    ● with double raw tires, the machine can move in either smooth road or bumpiness road.


  • Technical DataJBS30JBS40JBS30RJBS40R
    Max. Theo. Concrete Output (cbm/h)24303240
    Max. Concrete Pumping Pressure(MPa)108108
    Max Pumping Distance (m) (Vertical/Level)500/120400/100500/120400/100
    Power SystemElectricElectricDiesel EngineDiesel Engine
    Main Motor Power(KW)454562.562.5
    Rated speed(r/min)1480148020002000
    Main Oil Pump Discharge(ml/min)112140

    Concrete Tank Diameter/Stoke(mm)160*1000180*1000160*1000180*1000
    Main Oil Pump Tank Diameter*Stoke(mm)100*1000100*1000100*1000100*1000
    Hoist Hopper Volume (cbm)0.40.40.40.4
    Max. Aggregate Size(mm)40/30/2540/30/2540/30/2540/30/25
    Discharge Pipe Diameter(mm)140150140150
    Mixer Input Volume(m3)0.560.560.560.56
    Mixer Output Volume(m3)0.450.450.450.45
    Mixing Motor Power(KW)5.55.5

    Elevating Motor Power (KW)4.54.5

    Dimensions(L*W*H)(mm)4200*2300*26004800*2300*26004800*2300*26004800*2300*2600
    Total weight (KG)55005800600063000
