Model： JS2000
Discharging capacity： 2000L
Drum capacity： 3200L
Productivity (m3/h )： ≥120
Max.aggregate size(Cobble/Crushed Stone)(mm)： ≤80/100
Operation Recycle Time(S)： 60
Dimension Transport State (mm)： 3500*2400*2152
Weight(kg)： 7500

JS2000 Concrete Mixer

  • JS2000 concrete mixer is well applied in mixing various materials evenly with twin horizontal shaft & compulsory force. The efficient in producing concrete is 120m3/h. High-resistant manganese steel alloys plates and blades makes it has long service life. Besides it is environment-friendly with operational wear-resistant outside cover.

    It can work independently or in HZS120 concrete batching plant with PLD3200 batching machine.

    1. Made of high-resistant manganese steel Great power & High productivity with large capacity.

    2. Four pump cores supply oil directly to shafts' end lower failure rate of lubricating system.

    3. Easy to observe with simple design.


  •  Model  JS2000
     Discharging capacity  2000L
     Drum capacity  3200L
     Productivity (m3 /h )  ≥120
     Max.aggregate size(Cobble/Crushed Stone)(mm)  ≤80/100
     Operation Recycle Time(S)  60
     Dimension Transport State (mm)  3500*2400*2152
     Weight(kg)  7500
     Mixing Blade Rotate Speed  24.5r/min
     Mixing Blade Number  2x8
     Mixing Motor Model  Y250M-6
     Mixing Motor Power  2x37
     Discharging Height  4300mm
