Model: QT10-15
Exciting force (KN): 100
Vibration frequency(HZ): 0-60
Power(KW): 52.28
Forming type:  Fully automatic loading and molding
Forming cycle(S): 15-20
Outline dimension: 7500×2500×3020
Pallet size: 1220×900×25
Normal output: 14000

QT10-15 Concrete Block Making Machine

  • QT10-15 Fully-auto hydraulic cheap Concrete Block Making Machine:

    1.360 scatter mixer , greatly inproves the density and intensity of blocks.

    2.Hydraulic system: hydraulic spare parts be ordered according our block machine.

    3.All material and spare parts selected according international CE standard, Carbon dioxide pertection weldig will assure line stable running.

    4.We choose MITSUBISHI / SIEMENS programmable logic controller (PLC)

    5.Mold: newest heat treatment device assure longer mold life.


  •  Model Products Size Block Qty/Plate PCS/Hour PCS/8Hours
     QT10-15 Hollow Blocks 390×190×190 10 2400 19200
     Perforated Blocks 240×115×90 24 5760 46080
     Solid Blocks 240×115×53 48 11520 92160



    Model QT10-15
     Mixer JS750
     Batcher PLD1200
     Cement Silo sheet-assembled 100T
     Screw Conveyer LSY 219*8m
     Forming type Fully automatic loading and molding
     Control type PLC Semi-automatic control PLC
     Forming cycle (S) 15-20
     Outline dimension 7500×2500×3020
     Weight (T) 11
     Pallet size 1220×900×25
