1 Problems and causes of construction joint treatment

1.1 the problems of construction joints in the construction process are mainly manifested as the following phenomena: the concentration of concrete aggregates at the construction joints, the looseness of concrete, obvious new and old concrete joints, leakage along the cracks, etc.

1.2 causes of problems in construction joint treatment

(1) the concrete surface did not chisel hair treatment, residue did not wash clean, resulting in new and old concrete can not be combined firmly.

(2) in the process of support and binding of steel, sawdust, rubber belt, wood chips, nails and other debris into the seam did not remove in time, pouring the upper concrete, the formation of a sandwich between the old and new concrete.

(3) pouring the upper concrete, not in advance in the construction joint laid a layer of cement mortar, the upper and lower concrete can not be firmly bonded.

(4) no water stop is installed in the construction seam.

(5) improper cutting method, construction joint aggregate concentration, affect the quality of concrete.

(6) concrete wall is thin, because the reinforcement is too dense, ramming is difficult, resulting in concrete ramming is not dense.

(7) did not use compensation shrinkage concrete, resulting in stubble parts of shrinkage cracks.

(8) the seam form of construction seam selection is not appropriate.

2 Control of concrete pouring after treatment of construction joints

2.1 on hardened concrete surface, cement film, loose stones and weak concrete layer should be removed, and be fully wet and washed clean, and no water.

2.2 before pouring, a layer of 10mm ~ 15mm thick cement mortar should be laid on the horizontal construction joints, and the mixing ratio is the same as the mortar composition in the concrete.

2.3 concrete should be vibrated compacted without leakage or vibration to ensure the close combination of old and new concrete.

2.4 binding of rebar and wall support die.Should be considered to facilitate construction.Easy to ensure the quality of construction.

2.5 walls larger than 2m in height.It is advisable to use string tube or vibrating slide tube to cut the material and vibrate in layers.
